5052 Aluminum Round Bar | Marine Grade Aluminum Rod – HXM Aluminum

HXM Aluminum supplies 5052 aluminum round bar — a non-heat-treatable marine-grade alloy with excellent corrosion resistance, superior forming characteristics, and very good weldability. View all aluminum round bar grades →

5052 Aluminum Round Bar Specifications

Parameter	5052-H32 Round Bar
Alloy	5052 (Al-Mg)
Temper	H32, H34, O, H112
Diameter	6mm – 300mm (1/4” – 12”)
Length	1000mm – 6000mm, custom cut available
Tensile Strength	≥ 228 MPa (H32)
Yield Strength	≥ 193 MPa (H32)
Elongation	≥ 12%
Density	2.68 g/cm³
Standard	ASTM B211, EN 755-2, AMS 4015
Certificate	ISO 9001, MTC EN 10204 3.1

5052 Aluminum Chemical Composition (%)

Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Al
0.25 max	0.4 max	0.1 max	0.1 max	2.2–2.8	0.15–0.35	0.1 max	0.06 max	Balance

Why Choose 5052 Aluminum Round Bar?

• Excellent corrosion resistance — performs exceptionally in marine environments
• Superior forming — excellent bendability and cold working properties
• Very good weldability — TIG and MIG welding produce excellent results
• Non-heat-treatable — strength achieved through strain hardening
• Good surface finish — anodizes to a clean, attractive finish
